Toe Lasting Machine

Toe Lasting Machine

Toe Lasting Machine

Features

1.    This machine is used for the lasting operation of the upper’s forepart.

2.    Every pincer mounted on a patent tracking pincer plate, and are featuring with quick exchangeable and adjustable functions.

3.    Auto rotate the last pincer of left & right to perfect the inside waist lasting.

4.    Each set of pincer (left and right) can be setting with automatic pulling or manual operated preventing the upper made of different materials is only puller on one side.

5.    The upward and downward stroke of last support can be adjusted externally.

6.    There are two step upward movement functions for the last support, preventing the slipped of the last when combined with the movement of hell support.

7.    The toe pusher mechanism is designed with adjustable two step pressure. During the movement of the initial pressure, there are two ways (pressure controlled of position controlled) can be set for the best operation.

8.    The descending position of wiper seat is adjusted externally which is easy for operation.

9.    Quick exchangeable design for Wiper Blade and Toe Band.


Technical Specifications
Model No.KF-737
Pincers9
Pump Motor1.5 Kw(2 Hp)
Max. Power Consumption3.0 Kw (4 Hp)
Oil Pressure50 Kg/cm
Productivity180 Pairs/ Hour
Oil Tank Capacity115 Liters
N.W. / G.W.1050 Kg
